High precision , sensitive response.
Steady output pressure.
Large flow rate and steady flow output.
Easy installation : lndependent installation by bracket ; Bottom installation; Direct installation with existing modular air preparation.
High pressure type, medium pressure type and low pressure type optional.
Order Example：EPR3000 high precision regulator , 1/4" port, pressure range 0.01-0.8MPa ,with gauge.with bracket.scale unit MPa/psi,G thread. ERP code is EPR3000-02H.
| Model No. | EPR2000-01 | EPR3000-02 | EPR4000-02 | EPR4000-03 | EPR4000-04 | |
| Working Medium | Clean air(After 5 μm filteration) | |||||
| Max. Supply Pressure(Mpa) | 1.0 | |||||
| Min. Supply Pressure(Mpa) | Set Pressure+0.05 | Set Pressure+0.1 | ||||
| Proof Pressure(Mpa) | 1.5 | |||||
| Set Pressure | Low Pressure | L:0.005~0.2MPa L:0.01~0.2MPa | ||||
| Medium Pressure | M:0.01~0.4MPa | |||||
| High Pressure | H:0.01~0.8MPa | |||||
| Sensitivity | Within 0.2% of full scale | |||||
| Repeatability | Within 0.5% of full scale | |||||
| Air Consumption | ≤4.4L/min(ANR) | ≤11.5L/min (ANR) | ||||
| Port Size | 1/8” | 1/4” | 1/4" | 3/8" | 1/2" | |
| Pressure Gauge Port Size | G1/8(2 locations) | |||||
| Working Temperature(℃) | -20~70（No freezing） | |||||
| Weight（g） | 140 | 420 | 710 | |||
